The Wall Mount Fiber Patch Panel (termination box type) is designed for indoor wall installations where neat fiber termination, patching, and protection are required. It supports common adapter formats (SC/LC/ST/FC) with modular adapter plates and a hinged front door for easy access during maintenance.

Available Capacities (PDF Drawings)

• Wall Mount Fiber Patch Panel 24FO (PDF)
• Wall Mount Fiber Patch Panel 48FO (PDF)
• Wall Mount Fiber Patch Panel 96FO (PDF)

Wall Mount Fiber Patch Panel Features

• Wall-mount indoor enclosure: Ideal for telecom closets, customer premises, HUB/OTN sites, and co-location areas.
• Modular adapter plates: Field-configurable for SC, LC, ST, or FC adapters.
• Hinged front door: Easy access to patch cords and pigtails for service and troubleshooting.
• Splicing support: Compatible with splice tray kits (capacity depends on model/configuration).
• Secure closure: Spring-lock door mechanism for controlled access.
• Clean cable entry: Cable gland entry and internal routing for incoming/outgoing fibers.

Wall Mount Fiber Patch Panel Specifications

Product Type	Wall Mount Fiber Termination / Patch Panel Box
Installation	Wall Mount (Indoor)
Adapter Types	SC / LC / ST / FC (modular adapter plate)
Fiber Capacity Options	24FO / 48FO / 96FO (model dependent)
Splice Tray Support	Up to 4 trays (model dependent)
Cable Entries	Up to 2 cable entries (typical)
Material	Cold Rolled Steel Plate
Finish / Color	Electrostatic powder coating, Black (RAL 9005)
Lock	Spring Lock

Drawings (Images)

Typical Applications

• Telecommunications closets
• HUB / OTN sites
• Customer premises (CP)
• Co-location sites
• Campus / enterprise environments
• FTTH / FTTB networks

“This wall mount fiber patch panel is used as an indoor termination and patching point for FTTH/FTTB and telecom closets.”
